Flight 587 Debris Pictures; Mostly the Devastated Rudder

U.S. Coast Guard Photos by Mike Hvozda (numbered Part 1 to Part 9a)

Clicking each picture (Part 1 thru Part 9a) opens a multi-megabyte, high resolution version of the picture
I've included three reference pictures to assist you in identifying Parts 1 to 9a below (make sure you scroll down, there are 13 pictures on this page):




Reference Pic 1 - Airbus A300



Reference Pic 2 - Airbus A300 Vertical Stabilizer and Rudder


Reference Pic 3 - Flight 587's Vertical Stabilizer (minus the rudder)

Here are the Coast Guard Pictures (by Mike Hvozda)



Part 1 - Right (Starboard) Side of Rudder

The broken gray bottle is a fire bottle from the left engine strut/pylon (the large brace that attaches the engine to the wing). The black box is a high frequency antenna coupler from the vertical stabilizer.



Part 2 - Unknown



Part 3 - Most Likely Starboard Side Forward Base of Vertical Stabilizer



Part 4 - Upper Section of Rudder (Starboard)


Part 5 - Left (Port) Side Piece of Rudder


Part 6 - Top Piece Appears to be Starboard Side Piece of Rudder. Lower piece with the large curved end is the top of the rudder.


Part 7 - Different View of "Part 1" Rudder Piece from above


Part 8 - Different View of "Part 1" and "Part 7" Rudder Pieces from above


Part 9 - Starboard Side Vertical Stabilizer minus the rudder - notice the forward base is missing; this is the piece from "Part 3" from above


Part 9a - ditto
